Jackson USA Signature Misha Mansoor Juggernaut HT7FM Review & Prices
- From Jackson's 2018 Artist Signature series
- Misha Mansoor Signature
- Made in United States
- 7 strings
- 26.5"'' scale
- 20" Fretboard Radius
- Flame Maple top
- Caramelized Mahogany body
- Caramelized Quartersawn Maple neck
- Caramelized Flame Maple fretboard
- Bridge pickup: Bare Knuckle Juggernaut (Humbucker/Passive)
- Neck pickup: Bare Knuckle Juggernaut (Humbucker/Passive)
- 1 volume and 1 tone Dome knobs
- 5-way Switch
- Hipshot 7 Fixed .175 bridge
- Speed Bolt-On neck
- 24 Jumbo Stainless Steel frets
- Hipshot Open-Gear Locking tuners
- Compare Specs >
Our Scores and Tone Evaluation
- Heavy Metal
- Hard Rock
- Jazz
- Blues
- Funk
- Country
Jackson USA Signature Misha Mansoor Juggernaut HT7FM
- Stainless Steel Frets
- Locking Tuners
- Made in United States
- Expensive Wood
- Black Tusq XL Nut
- Top Brand Pickups
- Multi-Voicing Pickups
- Strap Lock
- No Neck-Through Build
- No Weight Relief
- No Luminescent Inlay
- No Tremolo
- No Compound Radius Fretboard
- No 21:1 Tuner Ratio
Price Overview
Its average competitor's price is $4000, which means that the Jackson USA Signature Misha Mansoor Juggernaut HT7FM costs around 25% more than the competition. It might be due to it having additional features, but know that you can find cheaper similar alternatives. This takes into account all instruments of the same category in our database with 7 strings and Fixed bridge that are made in United States.
These are affiliate links. We may earn a fee if you purchase after clicking. These prices are prone to error. Make sure you're buying the right product after clicking on a link from our site. We are not liable if you buy the wrong product after following these links. As an Amazon Associate site we earn from qualifying purchases.
Videos
Your feedback
Not all instruments are created equally. That's why it's important to have different opinions. Here's what our users who have played this instrument say. If you've played it before, help others by voting below!
Weight
VoteTuning stability
VoteNeck speed (thickness)
VoteNeck access to high frets
VoteNeck profile shape
VoteFret edges
VotePickups noise
VotePickups power
VoteIs it Easy to Play?
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM meets 6 out of our 8 criteria items for beginner friendliness, which means that it's a good guitar to start with as a complete beginner. This takes into account the type of frets, scale length, nut width, bridge type, fretboard radius, and neck profile to determine the easiest combination for new players to get used to.
New Player Friendliness
Jackson USA Signature Misha Mansoor Juggernaut HT7FM- Comfortable shape
- Easy-to-use bridge
- Locking tuners
- Tall frets
- Narrow nut
- Comfortable neck
- Comfortable fretboard
- Short scale
Hand Size Comfortability
After taking into account the neck profile, scale size, fretboard radius, and nut width, we can conclude that the Jackson USA Signature Misha Mansoor Juggernaut HT7FM's construction favors people with relatively small hands.
Nevertheless, this comes down in the end to personal preference. Make sure you test this guitar—or another one with similar characteristics—before buying.
Scale Length
Scale length is the distance the strings will span between the bridge and the nut. It can tell you a lot about the overall playability and tone of the instrument. A longer scale length means longer distance between frets, brighter tone and more string tension—which means lower action, but more difficult bending of the strings.
Here's the Jackson USA Signature Misha Mansoor Juggernaut HT7FM's 26.5" scale length compared to other common sizes:
This scale is close to the popular 25.50" length, but adding an additional inch allows you to tune your strings lower while keeping the action low without causing fret buzz. This is useful for lower tunings, 7-string, or even classical guitars.
You want to avoid such a long scale if you don't plan to play in low tunings since the longer scale also means the frets are more separated, making it harder to play fast, especially for small hands.
Neck Profile
The neck profile tells you the thickness (neck depth) and shape in cross section. Every difference will completely change the feeling and comfortability of the neck. This is a highly subjective thing, but most players indeed prefer certain types of necks (like Cs and Ds) because they feel nice in most hands.
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM's neck thickness is approximately 0.775'' (19.7mm) at the first fret, and 0.835'' (21.2mm) at the twelfth.
These measurements were taken either from the official Jackson website, or, in case this information wasn't provided, by researching multiple online marketplaces and forums where owners of this model have posted their measurements.
It has a D type neck. It's similar to a C shape, and it's one of the most common shapes right now. It's a bit flatter and thinner, even though sometimes it has a bit more shoulders. It's a fast type of neck that is comfortable, and shredders love it.
Fretboard Radius
When it comes to fingerboard radius, personal preference will dictate which one is better for you. However, most people seem to agree that a more curved (lower) radius will make it easier to play chords while a less curved (higher) radius is better for soloing and bending.
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM has a 20" fingerboard radius.
Here's an image comparing this fretboard radius to other popular choices:
This radius makes the fretboard almost completely flat, which means that it's perfect for playing single notes and bends. However, making complex chord shapes will be harder because you might mute the strings accidentally. It's a fretboard made for shredders, and probably for heavy music genres.
Compound radius fingerboards give the best of both worlds. Unfortunately, the Jackson USA Signature Misha Mansoor Juggernaut HT7FM has the same radius across the board.
Playability compared to main competitors
Nut Width
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM has a nut width of 44.5mm (1.75''). This is considered a narrow width for a 7-string guitar. This means that this guitar will have a narrower string separation at the nut, which will affect your fretting hand.
If you are a player with big hands, you might find it difficult to play chords without muting strings. However, this is good for players who have smaller hands, as it will allow them to reach each string more easily at the nut.
Frets
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM has 24 frets. A lot of people mistakenly believe that having more frets will always be better because it gives you a higher octave. This is certainly an advantage, but there's also a disadvantage to this.
Since the fretboard will be longer, the neck pickup will need to be placed closer to the bridge. And as you may know, the further away the neck pickup is from the bridge, the warmer it sounds. This means you'll have a brighter-sounding neck pickup when using a 24-fret guitar, even if you use the same pickup on a 22-fret guitar.
Finally, these are stainless steel frets. They're the best fretwire available. This means you won't need to change your frets since they should last as long as your guitar. Some people also feel easier bendings after swapping to stainless steel.
Fret Size
Finally, let's talk about fret size. Some people prefer tall frets because it's easier to press the strings and perform bends since there's less friction against the fretboard. On the other hand, some people like shorter frets because they like to touch the fretboard when playing, or because they got heavy hands and tend to press too much on the string and alter the of the note pitch accidently.
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM's frets are Jumbo size. This is a tall fret size that is becoming increasingly popular because it makes it easier to press down the strings cleanly. With this fret size, you won't feel the fretboard when playing, so if you press down too hard, you will get the notes out of pitch. However, this is something you can overcome by getting used to the taller size.
Playability Score
Tone Analysis
Wood will have little influence in the final tone of an electric guitar or bass. Instead, the hardware, especially the pickups, will be the most important thing to look at. Bur first, let's see the quality of the wood.
Wood
Mahogany Body: This is the type of wood found in many top-of-the-line guitars, so that's a positive point for the build quality. This red-looking wood Mahogany is found in Africa and Central America and has great sustain and a warm tone due to its high density. The downside about this type of wood is that it's relatively heavy.
Maple Neck: This is one of the most popular types of wood used in all kinds of guitars. It's heavy, strong and compact, which makes it great for necks. However, it's also used for fretboards, bodies and tops due to its light color, resistance and beautiful patterns. When it comes to tone, it highlights the mid and high frequencies.
Flame Maple Fretboard: This wood has beautiful patterns only found in specific types of maple.
Pickups
This guitar comes with pickups from one of the top brands: Bare Knuckle. So you can expect well built pickups with great sound that shouldn't need an upgrade anytime soon.
These are passive pickups, so you can expect a rounder sound and a moderade level of output.
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM's configuration is HH. With this pickup combination, you'll get warmer tones and more output than using single coils. Humbucker pickups cancel the noise that single-coil suffer from, which also results in a warmer tone. This pickup combination isn't only for high-gain music like Hard Rock or Heavy Metal. Their warmness is also popular for Jazz, Indie, R&B, Blues and more.
More with the same pickups
Versatility
It gives you a good amount of tone options with its 5-way switch. You can use it to choose at least 5 different pickup combinations.
It has a Multi-Voicing option. This means the pickups can change their output, tone, or sound. Piezo, Fishman and similar are considered multi-voicing pickups.
Diagram
What music genre is it good for?
As a 7 strings, Solid Body guitar with HH configuration and Passive pickups, we'd recommend it for genres like Heavy Metal or similar. However, you can use almost any guitar for any genre. This is just the typical type of music for this particular one.
Sound Score
Build Quality Analysis
Country of Origin
Knowing where the instrument is produced is a good way to know how well it's built. Some manufacturing countries are known for having higher quality standards. For example, most expensive instruments are made in the US or Japan, but there are some exceptionally great countries—like South Korea—that are building a good reputation.
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM is made in United States. Guitars made in the USA have the reputation of being the best instruments you can get. This statement isn't as accurate as a few years ago, but you should still expect top-quality from a guitar made in this country.
Bridge
Hipshot 7 Fixed .175: The advantage of fixed bridges is that they don't require any kind of set-up. This makes it extremely easy when changing strings because you don't need to adjust anything besides tuning the guitar. Also, the fact that the bridge is directly attached to the body will help to increase sustain. The disadvantage is the lack of versatility since you can't create the same vibrato effects as with tremolo bridges.
Tuners
The Jackson USA Signature Misha Mansoor Juggernaut HT7FM comes with locking tuners, which helps with tuning stability and makes changing strings a lot faster and easier. As long as they're high quality, these are the best tuning machines you can have. The only disadvantage is that they are a bit heavier than normal tuners.
Nut Material
Another important thing to analyze is the nut material, as it's one of the most important aspects that can affect the sound and playability of your guitar. A well-cut nut will make sure it stays in tune and will make it more comfortable to play.
In this case, the Jackson USA Signature Misha Mansoor Juggernaut HT7FM has a Black Tusq XL nut. It's not made of plastic or low-quality materials. They're made to resemble the sound you get from bone and ivory nuts, but with slippery materials so the intonation and tuning are stable. Also, each nut is carefully cut to ensure you won't have tune stabilization problems.
Neck Joint
The neck joint is the part where the neck of the guitar meets the body. There are three main techniques to attach both parts together: Set-In, Bolt-On and Neck-Through. The latter two provide different advantages, although neck-throughs are the most expensive.
This guitar has a Bolt-On neck joint. Even though this type of neck was looked down upon for a long time, nowadays bolt-on necks are well built and provide just as much sustain as any other join method. First of all, it's cheap to make because it consists of simply 4 bolts that attach the neck to the body. And you can travel with the guitar more easily, swap out the neck if you damage it, or upgrade to a more comfortable neck later on.
Build Quality Score
