ESP LTD SC-20 Review & Prices
- From ESP LTD's 2021 Signature series
- Stephen Carpenter Signature
- Made in Indonesia
- 6 strings
- 25.5"'' scale
- 13.78" Fretboard Radius
- Alder body
- 3pc Maple neck
- Macassar Ebony fretboard
- Bridge pickup: Seymour Duncan JB SH-4 (Humbucker/Passive)
- Middle pickup: ESP Designed LH-150N (Humbucker/Passive)
- Neck pickup: ESP Designed LS-120 (Single Coil/Passive)
- 1 volume and 1 tone Dome knobs
- 5-way Switch
- Tonepros Locking TOM w/ String Thru bridge
- Thin U Neck-Through neck
- 24 XL Jumbo frets
- LTD Locking tuners
- Weight between 7.45lbs (3.4kgs) and 7.75lbs (3.5kgs)
- Compare Specs >
Our Scores and Tone Evaluation
- Heavy Metal
- Hard Rock
- Jazz
- Blues
- Funk
- Country
ESP LTD SC-20
- Locking Tuners
- Expensive Wood
- Top Brand Pickups
- Neck-Through Build
- Luminescent Inlay
- Cheap Fret Wire (NS)
- Made in Indonesia
- No High-Quality Nut
- No Push Knob or Extra Switch Option
- No Weight Relief
- No Tremolo
- No Compound Radius Fretboard
- No 21:1 Tuner Ratio
- No Strap Lock
Price Overview
Its average competitor's price is $850, which means that the ESP LTD SC-20 costs around 41% more than the competition. It might be due to it having additional features, but know that you can find cheaper similar alternatives. This takes into account all instruments of the same category in our database with 6 strings and Fixed bridge that are made in Indonesia.
These are affiliate links. We may earn a fee if you purchase after clicking. These prices are prone to error. Make sure you're buying the right product after clicking on a link from our site. We are not liable if you buy the wrong product after following these links. As an Amazon Associate site we earn from qualifying purchases.
Videos
Your feedback
Not all instruments are created equally. That's why it's important to have different opinions. Here's what our users who have played this instrument say. If you've played it before, help others by voting below!
Weight
VoteTuning stability
VoteNeck speed (thickness)
VoteNeck access to high frets
VoteNeck profile shape
VoteFret edges
VotePickups noise
VotePickups power
VoteIs it Easy to Play?
The ESP LTD SC-20 meets 6 out of our 8 criteria items for beginner friendliness, which means that it's a good guitar to start with as a complete beginner. This takes into account the type of frets, scale length, nut width, bridge type, fretboard radius, and neck profile to determine the easiest combination for new players to get used to.
New Player Friendliness
ESP LTD SC-20- Comfortable shape
- Easy-to-use bridge
- Locking tuners
- Tall frets
- Narrow nut
- Comfortable neck
- Comfortable fretboard
- Short scale
Hand Size Comfortability
After taking into account the neck profile, scale size, fretboard radius, and nut width, we can conclude that the ESP LTD SC-20's construction favors people with relatively small hands.
Nevertheless, this comes down in the end to personal preference. Make sure you test this guitar—or another one with similar characteristics—before buying.
How Lightweight is it?
We found that the ESP LTD SC-20 weighs between 7.45lbs (3.4kgs) and 7.75lbs (3.5kgs). This was recorded from some online retailers that publish the weight of the instruments they sell.
Scale Length
Scale length is the distance the strings will span between the bridge and the nut. It can tell you a lot about the overall playability and tone of the instrument. A longer scale length means longer distance between frets, brighter tone and more string tension—which means lower action, but more difficult bending of the strings.
Here's the ESP LTD SC-20's 25.5" scale length compared to other common sizes:
This is the same scale length used in Stratocaster guitars, and it's one of the main reasons they have such a bright sound. It's considered a long scale when compared to most non-baritone guitars.
Since the distance between bridge and nut is relatively long, you'll need to give the strings more tension to get them in tune. This higher tension will allow for a couple of things. First, you can get a lower action (get the strings closer to the fretboard) because the strings won't 'wiggle' too much when pluck and won't cause fret buzz. This can allow you to use lower tunings without increasing your string gauge, and it will make it easier to press down the strings fast.
However, the frets will also have a wider separation between each other, which can make it harder to play, especially if you got small hands. The higher tension will also make the strings feel stiffer, so bending will require more strength.
Neck Profile
The neck profile tells you the thickness (neck depth) and shape in cross section. Every difference will completely change the feeling and comfortability of the neck. This is a highly subjective thing, but most players indeed prefer certain types of necks (like Cs and Ds) because they feel nice in most hands.
The ESP LTD SC-20's neck thickness is approximately 0.787'' (20mm) at the first fret, and 0.866'' (22mm) at the twelfth.
These measurements were taken either from the official ESP LTD website, or, in case this information wasn't provided, by researching multiple online marketplaces and forums where owners of this model have posted their measurements.
It has a U type neck. This shape usually has more 'shoulders' than a C neck. It's great for guitarists who love the feel of a vintage neck. Most of them are thick, which makes it better for people with big hands. However, some of them can be thin like a C neck but with more mass to the sides for a better grip.
Fretboard Radius
When it comes to fingerboard radius, personal preference will dictate which one is better for you. However, most people seem to agree that a more curved (lower) radius will make it easier to play chords while a less curved (higher) radius is better for soloing and bending.
The ESP LTD SC-20 has a 13.78" fingerboard radius.
Here's an image comparing this fretboard radius to other popular choices:
This makes it more similar to Gibson guitars (12'') than Fender (9.5''). It's slightly flatter than most modern Gibson fretboards though, which makes it more comfortable for single notes, bendings and vibratos, but less comfortable for chords.
Compound radius fingerboards give the best of both worlds. Unfortunately, the ESP LTD SC-20 has the same radius across the board.
Playability compared to main competitors
Nut Width
The ESP LTD SC-20 has a nut width of 42mm (1.654''). This is considered a narrow width for a 6-string guitar. This means that this guitar will have a narrower string separation at the nut, which will affect your fretting hand.
If you are a player with big hands, you might find it difficult to play chords without muting strings. However, this is good for players who have smaller hands, as it will allow them to reach each string more easily at the nut.
Frets
The ESP LTD SC-20 has 24 frets. A lot of people mistakenly believe that having more frets will always be better because it gives you a higher octave. This is certainly an advantage, but there's also a disadvantage to this.
Since the fretboard will be longer, the neck pickup will need to be placed closer to the bridge. And as you may know, the further away the neck pickup is from the bridge, the warmer it sounds. This means you'll have a brighter-sounding neck pickup when using a 24-fret guitar, even if you use the same pickup on a 22-fret guitar.
It comes with nickel silver frets, so they won't last as long as stainless steel frets. If you use your instrument a lot, you might need to replace the frets after a few years. But this is unlikely as most people change instruments before this happens.
Fret Size
Finally, let's talk about fret size. Some people prefer tall frets because it's easier to press the strings and perform bends since there's less friction against the fretboard. On the other hand, some people like shorter frets because they like to touch the fretboard when playing, or because they got heavy hands and tend to press too much on the string and alter the of the note pitch accidently.
The ESP LTD SC-20's frets are XL Jumbo size. These are extra-large frets, which are perfect for people who truly want the least resistance for techniques like vibrato, bending, tapping, and just playing fast in general. You won't be able to feel the fretboard with these frets, so if you press too hard you'll get the notes out of pitch. It might take a while to get used to them because of this.
Playability Score
Tone Analysis
Wood will have little influence in the final tone of an electric guitar or bass. Instead, the hardware, especially the pickups, will be the most important thing to look at. Bur first, let's see the quality of the wood.
Wood
Alder Body: This is a lightweight type of wood that was popularized by Fender. According to them, it's a wood that offers a balanced tone but that favors the upper midrange slightly.
Maple Neck: This is one of the most popular types of wood used in all kinds of guitars. It's heavy, strong and compact, which makes it great for necks. However, it's also used for fretboards, bodies and tops due to its light color, resistance and beautiful patterns. When it comes to tone, it highlights the mid and high frequencies.
Ebony Fretboard: This is one of the most expensive woods there is, which is why it's mostly used for fretboards. It is dense, heavy, highly resistant and comes in a really dark color that gives any guitar a classy touch. Tone wise, it helps the high side of the spectrum and provides good sustain.
Pickups
This guitar comes with pickups from one of the top brands: Seymour Duncan. So you can expect well built pickups with great sound that shouldn't need an upgrade anytime soon.
These are passive pickups, so you can expect a rounder sound and a moderade level of output.
The ESP LTD SC-20's configuration is HHS. Two humbuckers in the first position give you high output with a balanced tone for the rhythm, and the neck pickup will let you play crisp cleans similar to a Strat neck pickup. The middle humbucker combined with the neck single-coil gives a unique tone. The disadvantage of having a humbucker in the middle is that if it's set too tall, you might touch it with your pick while playing.
More with the same pickups
Versatility
It gives you a good amount of tone options with its 5-way switch. You can use it to choose at least 5 different pickup combinations.
Unfortunately, it doesn't come with more options for coil split or coil tapping. This makes it less versatile than some competitors.
Diagram
What music genre is it good for?
As a 6 strings, Solid Body guitar with HHS configuration and Passive pickups, we'd recommend it for genres like Hard Rock or similar. However, you can use almost any guitar for any genre. This is just the typical type of music for this particular one.
Sound Score
Build Quality Analysis
Country of Origin
Knowing where the instrument is produced is a good way to know how well it's built. Some manufacturing countries are known for having higher quality standards. For example, most expensive instruments are made in the US or Japan, but there are some exceptionally great countries—like South Korea—that are building a good reputation.
The ESP LTD SC-20 is made in Indonesia. Many people prefer the quality of an Indonesian guitar over a Chinese. Respectable brands like Epiphone, Ibanez and Schecter are building in this country because of the great quality and lower price. Some people like to compare them to the ones built in Japan during the 80s, when Japanese guitar makers made a name for themselves.
Bridge
Tonepros Locking TOM w/ String Thru: The advantage of fixed bridges is that they don't require any kind of set-up. This makes it extremely easy when changing strings because you don't need to adjust anything besides tuning the guitar. Also, the fact that the bridge is directly attached to the body will help to increase sustain. The disadvantage is the lack of versatility since you can't create the same vibrato effects as with tremolo bridges.
Tuners
The ESP LTD SC-20 comes with locking tuners, which helps with tuning stability and makes changing strings a lot faster and easier. As long as they're high quality, these are the best tuning machines you can have. The only disadvantage is that they are a bit heavier than normal tuners.
Nut Material
Another important thing to analyze is the nut material, as it's one of the most important aspects that can affect the sound and playability of your guitar. A well-cut nut will make sure it stays in tune and will make it more comfortable to play.
In this case, the ESP LTD SC-20 has a Plastic nut. This is a low-quality nut that you might want to consider upgrading soon. Bone and TUSQ nuts are the best for guitars with a fixed or simple tremolo bridge.
Neck Joint
The neck joint is the part where the neck of the guitar meets the body. There are three main techniques to attach both parts together: Set-In, Bolt-On and Neck-Through. The latter two provide different advantages, although neck-throughs are the most expensive.
This guitar has a Neck-Through neck joint. Many people believe a neck-through build delivers the best sustain because some of the vibrations from the neck aren't lost like with other neck joints. However, no one has been able to prove this. What we know is that a neck-through build is usually the most comfortable when playing the upper frets because there's nothing on your way at the neck-body joint.
Build Quality Score
All Specs
