Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple Review & Prices
- From Charvel's 2020 Pro-Mod series
- Made in Mexico
- 6 strings
- 25.5"'' scale
- 12" to 16" Fretboard Radius
- Quilt Maple top
- Mahogany body
- Maple neck
- Maple fretboard
- Bridge pickup: Seymour Duncan Full Shred SH-10B (Humbucker/Passive)
- Neck pickup: Seymour Duncan APH-1N (Humbucker/Passive)
- 1 volume and 1 tone Dome knobs
- 5-way Switch
- Floyd Rose 1000 Series Double-Locking Tremolo (Recessed) bridge
- Charvel Speed Bolt-On neck
- 24 Jumbo frets
- Charvel-Branded Die-Cast tuners
- Compare Specs >
Our Scores and Tone Evaluation
- Heavy Metal
- Hard Rock
- Jazz
- Blues
- Funk
- Country
Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple
- Expensive Wood
- Locking Nut
- Top Brand Pickups
- Tremolo
- Compound Radius Fretboard
- Retainer Bar
- Cheap Fret Wire (NS)
- No Locking Tuners
- Made in Mexico
- No Neck-Through Build
- No Push Knob or Extra Switch Option
- No Weight Relief
- No Luminescent Inlay
- No 21:1 Tuner Ratio
- No Strap Lock
Price Overview
Its average competitor's price is $1150, which means that the Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple is around 13% cheaper than the competition. This takes into account all instruments of the same category in our database with 6 strings and Double Locking bridge that are made in Mexico.
These are affiliate links. We may earn a fee if you purchase after clicking. These prices are prone to error. Make sure you're buying the right product after clicking on a link from our site. We are not liable if you buy the wrong product after following these links. As an Amazon Associate site we earn from qualifying purchases.
Videos
Your feedback
Not all instruments are created equally. That's why it's important to have different opinions. Here's what our users who have played this instrument say. If you've played it before, help others by voting below!
Weight
VoteTuning stability
VoteNeck speed (thickness)
VoteNeck access to high frets
VoteNeck profile shape
VoteFret edges
VotePickups noise
VotePickups power
VoteIs it Easy to Play?
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple meets 4 out of our 8 criteria items for beginner friendliness, which means that it's not bad for beginners, but it could be better. This takes into account the type of frets, scale length, nut width, bridge type, fretboard radius, and neck profile to determine the easiest combination for new players to get used to.
New Player Friendliness
Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple- Comfortable shape
- Comfortable fretboard
- Tall frets
- Comfortable neck
- Narrow nut
- Short scale
- Locking tuners
- Easy-to-use bridge
Hand Size Comfortability
After taking into account the neck profile, scale size, fretboard radius, and nut width, we can conclude that the Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple's construction favors people with relatively small hands.
Nevertheless, this comes down in the end to personal preference. Make sure you test this guitar—or another one with similar characteristics—before buying.
Scale Length
Scale length is the distance the strings will span between the bridge and the nut. It can tell you a lot about the overall playability and tone of the instrument. A longer scale length means longer distance between frets, brighter tone and more string tension—which means lower action, but more difficult bending of the strings.
Here's the Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple's 25.5" scale length compared to other common sizes:
This is the same scale length used in Stratocaster guitars, and it's one of the main reasons they have such a bright sound. It's considered a long scale when compared to most non-baritone guitars.
Since the distance between bridge and nut is relatively long, you'll need to give the strings more tension to get them in tune. This higher tension will allow for a couple of things. First, you can get a lower action (get the strings closer to the fretboard) because the strings won't 'wiggle' too much when pluck and won't cause fret buzz. This can allow you to use lower tunings without increasing your string gauge, and it will make it easier to press down the strings fast.
However, the frets will also have a wider separation between each other, which can make it harder to play, especially if you got small hands. The higher tension will also make the strings feel stiffer, so bending will require more strength.
Neck Profile
The neck profile tells you the thickness (neck depth) and shape in cross section. Every difference will completely change the feeling and comfortability of the neck. This is a highly subjective thing, but most players indeed prefer certain types of necks (like Cs and Ds) because they feel nice in most hands.
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple's neck thickness is approximately 0.77'' (19.6mm) at the first fret, and 0.83'' (21.1mm) at the twelfth.
These measurements were taken either from the official Charvel website, or, in case this information wasn't provided, by researching multiple online marketplaces and forums where owners of this model have posted their measurements.
It has a C type neck. C-shaped necks like this have been the most popular for the last years. The reason is that they feel good in most hands. It's generally a thin neck that doesn't get in your way when playing fast, but that also has enough mass to give your hands a comfortable grip for chords if they aren't too big.
Thin necks like this make it easier to move your hand across the neck and it helps when playing fast solos, especially if you like to leave your thumb free while playing high on the fretboard. However, thinner necks are also weaker and will need adjustment more often than a thicker neck.
Fretboard Radius
When it comes to fingerboard radius, personal preference will dictate which one is better for you. However, most people seem to agree that a more curved (lower) radius will make it easier to play chords while a less curved (higher) radius is better for soloing and bending.
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple has a compound fingerboard radius of 12" to 16".
A compound radius is the best you can get because you'll get the best of both worlds. It starts curved at the nut, but it flattens as you get closer to the body. This means that you'll get great comfortability for chords on the first few frets, but also a flatter fretboard for playing solos without problems on the higher frets.
Playability compared to main competitors
Nut Width
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple has a nut width of 42.9mm (1.688''). This is within the most common range of nut widths for a 6-string guitar. It offers a good balance of string separation at the nut. It's the size that most guitarists prefer as it gives them just enough space to play open chords without muting the strings, but without spreading the strings too wide and making bar chords difficult to perform.
Frets
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple has 24 frets. A lot of people mistakenly believe that having more frets will always be better because it gives you a higher octave. This is certainly an advantage, but there's also a disadvantage to this.
Since the fretboard will be longer, the neck pickup will need to be placed closer to the bridge. And as you may know, the further away the neck pickup is from the bridge, the warmer it sounds. This means you'll have a brighter-sounding neck pickup when using a 24-fret guitar, even if you use the same pickup on a 22-fret guitar.
It comes with nickel silver frets, so they won't last as long as stainless steel frets. If you use your instrument a lot, you might need to replace the frets after a few years. But this is unlikely as most people change instruments before this happens.
Fret Size
Finally, let's talk about fret size. Some people prefer tall frets because it's easier to press the strings and perform bends since there's less friction against the fretboard. On the other hand, some people like shorter frets because they like to touch the fretboard when playing, or because they got heavy hands and tend to press too much on the string and alter the of the note pitch accidently.
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple's frets are Jumbo size. This is a tall fret size that is becoming increasingly popular because it makes it easier to press down the strings cleanly. With this fret size, you won't feel the fretboard when playing, so if you press down too hard, you will get the notes out of pitch. However, this is something you can overcome by getting used to the taller size.
Playability Score
Tone Analysis
Wood will have little influence in the final tone of an electric guitar or bass. Instead, the hardware, especially the pickups, will be the most important thing to look at. Bur first, let's see the quality of the wood.
Wood
Mahogany Body: This is the type of wood found in many top-of-the-line guitars, so that's a positive point for the build quality. This red-looking wood Mahogany is found in Africa and Central America and has great sustain and a warm tone due to its high density. The downside about this type of wood is that it's relatively heavy.
Maple Neck and Fretboard: This is one of the most popular types of wood used in all kinds of guitars. It's heavy, strong and compact, which makes it great for necks. However, it's also used for fretboards, bodies and tops due to its light color, resistance and beautiful patterns. When it comes to tone, it highlights the mid and high frequencies.
Pickups
This guitar comes with pickups from one of the top brands: Seymour Duncan. So you can expect well built pickups with great sound that shouldn't need an upgrade anytime soon.
These are passive pickups, so you can expect a rounder sound and a moderade level of output.
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple's configuration is HH. With this pickup combination, you'll get warmer tones and more output than using single coils. Humbucker pickups cancel the noise that single-coil suffer from, which also results in a warmer tone. This pickup combination isn't only for high-gain music like Hard Rock or Heavy Metal. Their warmness is also popular for Jazz, Indie, R&B, Blues and more.
More with the same pickups
Versatility
It gives you a good amount of tone options with its 5-way switch. You can use it to choose at least 5 different pickup combinations.
Unfortunately, it doesn't come with more options for coil split or coil tapping. This makes it less versatile than some competitors.
Diagram
What music genre is it good for?
As a 6 strings, Solid Body guitar with HH configuration and Passive pickups, we'd recommend it for genres like Hard Rock or similar. However, you can use almost any guitar for any genre. This is just the typical type of music for this particular one.
Sound Score
Build Quality Analysis
Country of Origin
Knowing where the instrument is produced is a good way to know how well it's built. Some manufacturing countries are known for having higher quality standards. For example, most expensive instruments are made in the US or Japan, but there are some exceptionally great countries—like South Korea—that are building a good reputation.
The Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple is made in Mexico. This is the country that some American brands choose for building really good, but cheaper guitars. You can expect a guitar that offers a good price-quality relationship, although they don't get the same quality control as the ones built in Japan or the United States.
Bridge
Floyd Rose 1000 Series Double-Locking Tremolo (Recessed): With this type of tremolo bridge, you'll be able to perform dive bombs and pinch harmonics without getting out of tune. This type of bridge gives you the best versatility, but it also makes it harder to set up your guitar correctly, especially when changing your strings.
Nut Material
Another important thing to analyze is the nut material, as it's one of the most important aspects that can affect the sound and playability of your guitar. A well-cut nut will make sure it stays in tune and will make it more comfortable to play.
In this case, the Charvel Pro-Mod DK24 HH FR M Mahogany with Quilt Maple has a Locking nut. Instead of the typical nut, this nut locks the strings in place and will make them stay in tune even after heavy tremolo use. This type of nut provides the best tune stability, but they also make the guitar more expensive.
It also comes with a retainer bar for the locking nut, which is a helpful addition. Without it, the strings would change pitch once you lock down the nut, so you'd have to make more micro-adjustments at the bridge to tune it correctly.
Neck Joint
The neck joint is the part where the neck of the guitar meets the body. There are three main techniques to attach both parts together: Set-In, Bolt-On and Neck-Through. The latter two provide different advantages, although neck-throughs are the most expensive.
This guitar has a Bolt-On neck joint. Even though this type of neck was looked down upon for a long time, nowadays bolt-on necks are well built and provide just as much sustain as any other join method. First of all, it's cheap to make because it consists of simply 4 bolts that attach the neck to the body. And you can travel with the guitar more easily, swap out the neck if you damage it, or upgrade to a more comfortable neck later on.
Build Quality Score
